AF Cover iav
AF Npog iav integrates ruaj khov los tiv thaiv- ntiv tes nanotechnology ncaj qha mus rau hauv lub iav nto uas muab kev tiv thaiv ntev tiv thaiv roj thiab smudges. Lub iav engineered no tuav superior optical clarity rau cov lus qhia nyob rau hauv cov neeg siv khoom electronics automotive interfaces thiab cov khoom siv.
- Kev xa khoom sai
- Quality Assurance
- 24/7 Kev Pabcuam Cov Neeg Siv Khoom
Khoom Taw qhia
Kev cai AF Coated Cover iav rau OEM daim ntaub ntawv
Koj lub vijtsam puv nrog ntiv tes? Vim tsis muaj AF txheej.
Lub AR txheej tuaj yeem raug tshem tawm yooj yim? AF txheej tuaj yeem tiv thaiv nws.
AF txheej tev tawm yooj yim? Vim qhov zoo thiab tshuaj tsuag AF txoj kev.
GL iav yog cov iav kev tshaj lij OEM feem ntau tsom rau cov khoom siv hluav taws xob, khoom siv thiab khoos phis tawj. Tom qab xyoo kev loj hlob, peb muaj tag nrho cov thev naus laus zis xws li txiav, sib tsoo, laser, silkscreen, tempering, txheej txheej sib txawv. Peb tau koom tes nrog ntau lub tuam txhab nto moo, thiab yeej kev qhuas ntawm lub chaw tshawb fawb iav hauv zos thiab cov tuam txhab thev naus laus zis siab, peb ntseeg tias tuaj yeem txaus siab rau koj cov kev xav tau tshwj xeeb.
AF Txheej Parameters
|
Parameter |
Electroplated AF Txheej |
Txau- ntawm AF Txheej |
Txoj Kev Xeem |
|---|---|---|---|
|
Txheej Thickness |
5-15 nm |
8-25 nm |
SEM / AFM |
|
Water Contact Angle (WCA) |
Ntau tshaj lossis sib npaug li 115 degree |
Ntau dua lossis sib npaug li 110 degree |
Sessile Drop Method |
|
n-Hexadecane Contact Angle |
65-72 degree |
60-68 degrees |
Sessile Drop Method |
|
Durability (Kev siv tsis tu ncua) |
12–24 Lub Hlis |
4–8 Lub Hlis |
Tiag -World Wear Test |
|
Abrasion Resistance |
Ntau dua lossis sib npaug rau 5,000 Cycles (1000g load, Steel Wool #0000) |
Ntau tshaj lossis sib npaug rau 2,000 Cycles (1000g load, Steel Wool #0000) |
Linear Abraser |
|
Adhesion (Cross-Kev Ntsuas Txiav) |
5B (tsis muaj tev) |
4B–5B |
ASTM D 3359 Cov Lus Qhia Tshwj Xeeb |
|
Pencil Hardness |
Ntau dua lossis sib npaug li 6H |
Ntau dua lossis sib npaug li 5H |
Cwj mem Hardness Test |
|
Lub teeb Transmittance |
Ntau dua lossis sib npaug li 91% |
Ntau dua lossis sib npaug li 90% |
UV-Vis Spectrophotometer |
|
Kev khiav hauj lwm qhov kub thiab txias |
-40℃rau +85 degree |
-30℃rau +80 degree |
Thermal Cycling Test |
Qhov tseem ceeb ntawm AF Coated iav rau Electronic Displays los ntawm gL iav
1. Durability uas kav ntev
Cov txheej txheej feem ntau siv cov tshuaj tsuag yooj yim- ntawm daim ntawv thov uas hnav tawm hauv lub lis piam. Peb siv lub tshuab nqus tsev vacuum deposition, tsim ib daim ntawv cog lus molecular uas tiv taus 15, 000+ steel wool abrasion tests. Cov neeg sib tw feem ntau poob tom qab tsuas yog 500-1,000 lub voj voog.
2. Kev sib cuag dej siab dua
Peb txheej ua tiav 113℃dej sib cuag lub kaum sab xis, piv rau kev lag luam nruab nrab ntawm 100℃-105 degree. Qhov tshwm sim? Cov roj thiab cov ntiv tes rub tawm thiab so tawm kom tsis muaj zog- tsis muaj smudges sab laug.
3. Zero Haze, Full Clarity
Cov coatings pheej yig dua feem ntau qhia cov cua daj cua dub lossis hloov qhov ntsuas qhov ntsuas tsis pom, dimming zaub zoo. Peb tuav 93% + lub teeb kis nrog<0.5% haze, ensuring crystal-clear optics for high-end screens and automotive displays.
AF Npog iav khoom siv
Consumer Electronics Series
Smartphone thiab Tablet Display Glass
Laptop thiab Saib Npog iav
Wearable Device Face iav
01
Automotive Qib Series
Center Console Display iav
Digital Instrument Cluster Glass
Tsheb Rooj Lom Zem iav
02
Industrial Qib Series
Tswj Vaj Huam Sib Luag Interface Glass
Cov cuab yeej kho mob zaub iav
POS System Kov iav
03
Daim Ntawv Thov Tshwj Xeeb Series
Anti Glare AF Composite iav
Anti Reflective AF Composite iav
Custom Shape Precision Cut Glass
04
Tsev Khoom Series
Ntse Tsev Tswj iav
Chav ua noj khoom siv Interface iav
Automation System Zaub iav
05
Vim li cas thiaj xaiv GL iav
Swift Project tiav
Kev xa khoom hauv 7-10 hnub
Qauv npaj ua ntej 3-5 hnub
Comprehensive Technical Capacity
Ua kom tiav hauv - cov khoom siv hauv tsev
Customized manufacturing daws
Kev Pabcuam Dedicated
Cov kws tshaj lij tom qab- pab pawg muag khoom
Ntev -kev koom tes hauv lub sijhawm
Excellence nyob rau hauv Quality
Multi-stage soj ntsuam system
Certified zoo qauv
Instant Response Assurance
Ob -teev teb thawj zaug
Tib - hnub kev daws teeb meem
Peb daim ntawv pov thawj
Optimized FAQs: AF Coated iav
Q1: Dab tsi ntawm AF coatings koj muab thiab dab tsi yog qhov sib txawv tseem ceeb?
Peb feem ntau muab ob qho kev daws teeb meem AF txheej txheem kom haum rau qhov kev xav tau sib txawv thiab kev siv nyiaj txiag:
PVD (Physical Vapor Deposition) Txheej: Lub tshuab nqus tsev no -plating txheej txheem tsim ib qho tshwj xeeb ruaj khov, siab - txheej txheej nrog superior oleophobic (roj-repellent) cov khoom thiab ntev - lub neej lifespan. Nws yog qhov kev xaiv zoo tshaj plaws rau siab -kawg cov khoom siv hluav taws xob thiab cov ntawv thov uas yuav tsum tau ua kom ntev ntev.
Txau Txheej: Tus nqi - siv tau zoo los ntawm kev txau tshuaj. Thaum nws muaj kev ua tau zoo thawj zaug, nws qhov kev tiv thaiv rau kev puas tsuaj thiab tshuaj lom neeg yog nruab nrab, nrog rau kev ua haujlwm ntawm lub neej feem ntau kav ntev rau ntau txhiab lub voj voog. Nws yog qhov tsim nyog rau cov ntawv thov uas tsis tshua siv ntau zaus lossis kev txwv nyiaj txiag nruj dua.
Q2: Peb tuaj yeem muab peb cov kev qhia tshwj xeeb kom tau txais kev kho AF coated iav?
Peb muab ob txoj hauv kev yooj yim los pib koj qhov project:
Txoj Kev Nyiam: Thov qhia koj cov ncauj lus kom ntxaws engineering nrog txhua yam tsis muaj (khoom siv, thickness, qhov ntev, kam rau ua, thiab lwm yam) txhais tau. Qhov no ua kom qhov tseeb tshaj plaws hais thiab ceev tshaj plaws turnaround.
Lwm Txoj Kev: Yog tias tsis muaj daim duab kos, tsuas yog muab txhua qhov kev paub txog qhov ntev, qhov yuav tsum tau ua, thiab daim ntawv thov lub hom phiaj. Peb pab neeg ua haujlwm engineering yuav txheeb xyuas koj cov kev xav tau thiab tuaj yeem tsim cov qauv tsim rau koj qhov kev pom zoo.
Q3: Dab tsi yog koj lub sijhawm ua haujlwm rau kev muab cov qauv?
Cov sij hawm ua piv txwv txawv raws li cov txheej txheem txheej txheem thiab cov iav ua qhov nyuaj.
Standard AF Txheej Qauv: tuaj yeem npaj sai li 1-3 hnub ua haujlwm.
Cov Kev Ua Haujlwm Zoo: (Nrog cov kauj ruam ntxiv xws li kev txiav, etching, lossis AR / AG ua ke) yuav xav tau txog li 5 hnub ua haujlwm.
Peb yuav muab ib qho piv txwv ncua sij hawm raws li kev tshuaj xyuas koj cov kev xav tau.
Q4: Koj puas yog cov chaw tsim khoom lossis lub tuam txhab lag luam?
Peb yog cov chaw tsim khoom. Peb muaj nyob rau hauv -cov chaw tsim khoom hauv tsev thiab ib pab neeg ua haujlwm siab, tso cai rau peb tswj xyuas qhov zoo thiab tsim cov iav npog ncaj qha raws li koj qhov kev cai tsim thiab kev qhia tshwj xeeb.
Q5: Koj lub peev xwm rau iav thickness yog dab tsi?
Peb cov txheej txheem tsim khoom txhawb nqa ntau yam thicknesses kom tau raws li ntau hom kev thov.
Standard Thickness Range: Peb niaj hnub ua iav los ntawm 0.2mm txog 22mm.
Khoom Dependency: Qhov tshwj xeeb muaj thickness yuav txawv me ntsis nyob ntawm seb lub hauv paus iav khoom (xws li, dej qab zib- txiv qaub, aluminosilicate). Peb tuaj yeem qhia txog cov khoom siv zoo tshaj plaws thiab tuab ua ke rau koj qhov project.
